Reconstruction of the Cummins QSB 4.5 Engine in the Dynapac CA2500D Roller

Overhaul of the Cummins QSB 4.5 Engine in a Dynapac CA2500D Vibratory Soil Roller

The Dynapac CA2500D is a vibratory soil roller designed for intensive soil compaction work, commonly used during road construction and modernization, preparation of construction sites and other earthworks. In machines of this type, the diesel engine operates under demanding conditions because it must provide stable performance not only while the roller is moving, but also during prolonged operation under load associated with the vibration system. In the case described here, the subject of the repair was a Cummins QSB 4.5 engine installed in a Dynapac CA2500D roller.

The engine overhaul was carried out due to symptoms indicating wear of components in the crankshaft and piston assembly, particularly the crankshaft and connecting rod bearings. Before deciding on a complete rebuild of the power unit, we carried out diagnostics while the engine was still installed in the machine. This allowed us to determine the nature of the problem and plan the subsequent work. After removal, the engine was transported to our facility in Kojszówka, where it was disassembled, cleaned and subjected to a detailed inspection of individual components.

WIBAKO provides comprehensive construction machinery service, including diagnostics, engine removal and installation, as well as overhauls of power units used in off-highway machines. In the case of Cummins engines, we also carry out work involving the inspection of mechanical components and preparation of the engine for operation under load. An important part of the process is testing the engine after overhaul on an engine dynamometer, which allows its operation to be checked under load before it is installed back into the machine.

Diagnostics of the Cummins QSB 4.5 Engine in the Dynapac CA2500D

The first stage of the work was diagnostics of the Cummins QSB 4.5 engine directly in the Dynapac CA2500D roller. When diagnosing a power unit operating in construction machinery, simply observing the symptoms is not enough to determine the scope of the overhaul. It is necessary to check the basic operating parameters of the engine and relate them to its behaviour during actual operation.

First, we checked the way the engine operated at idle and while increasing engine speed. We paid attention to mechanical noises, vibrations and operating stability. We then checked the basic parameters associated with the lubrication system. Oil pressure was particularly important, as a drop in oil pressure can be one of the symptoms of worn crankshaft or connecting rod bearings.

As part of the further diagnostics, we also assessed the condition of the engine oil and oil filter. The presence of metallic contamination or particles in the lubrication system may indicate progressive wear of components working together inside the engine. In the case of the Cummins QSB 4.5, the symptoms indicated the need for a detailed inspection of the crankshaft and piston assembly.

At this stage, however, we did not assume that only one component was damaged. The final scope of the overhaul can only be determined after disassembling the engine. For this reason, after completing the initial diagnostics in the machine, the decision was made to remove the power unit and carry out a detailed inspection under workshop conditions.

Removal of the Engine from the Dynapac CA2500D

The engine was removed from the Dynapac CA2500D by our mechanics using a crane provided by the customer. During engine removal, it is important not only to disconnect the power unit itself, but also to properly secure all components that remain in the machine or will be reused during installation.

The work began with preparing the machine for safe engine removal. Components of the cooling system and the lines and connections that had to be disconnected from the engine were secured. We then disconnected the electrical wiring, fuel system lines, air intake components and connections associated with the remaining engine accessories.

An important part of the work was also marking and organizing individual lines and connections. This makes it possible to maintain the correct position of the components during subsequent installation and reduces the risk of incorrect connections. We pay particular attention to cooling system hoses, intake system components and fuel system lines because their correct connection directly affects the safety and proper operation of the engine after start-up.

After disconnecting the accessories and mounting components, the engine was prepared for removal from the engine compartment. The crane provided by the customer was used to safely lift the power unit and remove it from the machine. Once removal was complete, the engine was properly secured and prepared for transportation to our facility in Kojszówka.

Engine removal performed by the WIBAKO mobile service allows us to limit the amount of work that has to be carried out at the customer's site. Our mechanics can perform the necessary operations directly at the machine and then transport the engine to our workshop, where suitable workstations and equipment are available for detailed inspection and overhaul.

Inspection of the Cummins QSB 4.5 Engine in the Workshop

After the engine was delivered to the workshop, we began the disassembly process. The unit was dismantled into individual components, which were cleaned and inspected as the work progressed. Engine inspection is not limited to visual examination. In the case of components belonging to the crankshaft and piston assembly, accurate measurements are necessary to determine whether a component can be reused, requires reconditioning or should be replaced with a new one.

In this engine, particular attention was paid to the crankshaft, bearings and connecting rods. The earlier diagnostics indicated wear in this area of the power unit. Once the engine had been disassembled, it was possible to assess the condition of the mating surfaces in greater detail and determine whether the wear had caused additional damage.

The crankshaft was visually inspected for signs of wear, overheating and possible damage. The crankshaft journals were then measured and runout was checked. The oil passages were also inspected because their condition is important for proper lubrication of the bearings and other engine components.

The connecting rods were inspected for wear, cracks and signs of overheating. The inspection also included checking their geometry, including twisting and longitudinal bending, as well as examining the fastening components. The bearings were assessed for wear and the condition of their surfaces in contact with the crankshaft.

Other engine components were also inspected because a comprehensive overhaul requires checking the entire power unit rather than only the component responsible for the initial symptoms. Components of the cylinder head, timing system and engine accessories were also inspected.

Overhaul of the Crankshaft and Piston Assembly

The most important stage of the Cummins QSB 4.5 overhaul was rebuilding the crankshaft and piston assembly. These components are responsible for transferring the force generated during combustion to the crankshaft. In an engine operating under load in a soil roller, all of these components must maintain the correct parameters and provide proper lubrication.

After measurements had been completed, the condition of the crankshaft was determined. Where component surfaces require reconditioning, the scope of work is established based on actual measurement results. Crankshaft reconditioning may include grinding if the condition of the component allows this operation and the correct dimensions of the mating surfaces can be restored.

The connecting rods were also inspected. Checking their geometry is important because even small deformations can affect the correct cooperation of the piston, piston pin, connecting rod and crankshaft. The fastening components were checked for their technical condition.

As part of the rebuilding of the crankshaft and piston assembly, the pistons, rings, cylinder liners and bearings are also inspected. Each component must be assessed for wear. Depending on the inspection results, components are either replaced or appropriately reconditioned.

Once all components had been prepared, the crankshaft and piston assembly was assembled. During assembly, particular attention is paid to the correct sequence of operations, measurement accuracy and inspection of mating surfaces. After the overhaul, the Cummins QSB 4.5 engine must be assembled in a way that ensures proper operation of all components both during the first start-up and during subsequent operation of the Dynapac CA2500D roller.

Inspection and Repair of the Engine Cylinder Head

The next stage was inspection of the cylinder head of the Cummins QSB 4.5 engine. The cylinder head was thoroughly cleaned and inspected to determine whether it could be reused. The valve seats, guides and valves were checked. The cylinder head's sealing condition was also inspected.

The cylinder head pressure test consists of immersing the component in heated water and then applying compressed air. Observing the cylinder head during the test makes it possible to identify areas where air could escape. This inspection allows us to determine whether the cylinder head can be reused after the necessary work has been carried out.

Depending on the degree of wear, cylinder head reconditioning includes operations such as resurfacing, replacement of valve guides and valves. The scope of work is always determined by the actual inspection results. We do not assume that every component must be replaced without first checking its condition, because the purpose of an overhaul is to restore the engine to proper technical condition based on actual measurements and inspections.

Inspection of the Cummins QSB 4.5 Engine Accessories

During the overhaul, the engine accessories were also inspected. Components that may affect the correct operation of the engine after it is started were checked. This included, among other things, the turbocharger and electro-mechanical components.

The turbocharger was inspected for axial and radial play. This inspection makes it possible to determine the condition of its rotating components and assess whether it can be reused in the rebuilt power unit.

The starting and charging system components were also checked, including the starter motor and alternator. During a comprehensive engine rebuild, it is important not only to prepare the main mechanical components, but also to inspect the components required for proper starting and operation of the power unit in the machine.

Professional Assembly of the Cummins QSB 4.5 Engine

Once the inspection had been completed and the components prepared, we began assembling the Cummins QSB 4.5 engine. The assembly was carried out in stages according to the adopted work procedure. The crankshaft and piston assembly was prepared first, followed by the remaining engine components.

During assembly, particular attention is paid to the cleanliness of all surfaces and the correct preparation of components before installation. The lubrication system must be free from contamination because residues from previous wear can negatively affect newly prepared components.

After the main engine components had been assembled, the remaining accessories were installed. All connections must be made in a way that ensures proper operation of the power unit. Before the first start-up, a visual inspection and a check of the most important connections are carried out.

The prepared Cummins QSB 4.5 engine was then moved to the next stage - testing on the engine dynamometer. Testing the unit before installing it back into the Dynapac CA2500D allows us to check its behaviour under load and obtain additional information about its operation.

Testing the Cummins QSB 4.5 Engine on the Engine Dynamometer

One of the important elements of the overhaul process at WIBAKO is engine dynamometer testing. Thanks to the dynamometer, we can start the rebuilt engine and check its behaviour under load before installing it back into the machine. In the case of the Cummins QSB 4.5 intended for the Dynapac CA2500D, this stage was an important part of verifying the completed rebuild.

A dynamometer test differs from simply starting an engine on a workshop stand. The fact that an engine starts does not by itself mean that all components are operating correctly under load. During a dynamometer test, the engine can be subjected to load corresponding to operating conditions, making it possible to observe its behaviour under significantly more demanding conditions.

After an overhaul, the engine is started and operated for a minimum of 16 hours under light working conditions, with a load of approximately 20-30% of the nominal value. This stage is important for monitoring the initial operating period after rebuilding the unit. Mechanics can observe the stability of operating parameters, temperature, oil pressure and the general behaviour of the engine.

Gradually increasing the load makes it possible to monitor the engine without suddenly moving from the first start-up to maximum operating conditions. If the engine maintains its basic operating parameters during the initial stage, the load is increased further. The unit is then repeatedly operated under higher loads to check its correct performance.

During the test, the main engine operating parameters are monitored. Particular attention is paid to the lubrication system, temperature stability and the engine's response to changes in load. We also monitor for abnormal noises, vibrations and other symptoms that could indicate a problem with any of the components.

The dynamometer also makes it possible to check the engine's behaviour while moving between different load levels. This is particularly important for a power unit that will return to construction machinery operating under changing conditions. The Dynapac CA2500D may operate for extended periods under considerable load, so the engine must be properly prepared for this type of operation.

An important advantage of testing the unit before installation is the possibility of detecting potential problems while the engine is still in the workshop. If any irregularities occur during the test, our mechanics can carry out additional diagnostics without having to remove the engine from the machine again. This reduces the risk of installing a unit that still requires additional inspection.

The dynamometer test is therefore another stage of verification following the previous measurements and mechanical work. It does not replace inspection of individual components, but it provides a practical check of the complete assembled engine. In the case of the Cummins QSB 4.5 overhaul for the Dynapac CA2500D, this made it possible to verify the power unit as a complete assembly before returning it to the machine.

After the dynamometer test was completed and the engine's correct operation had been confirmed, the power unit was prepared for transportation and reinstallation in the roller. The previous load test provided additional information about the engine's behaviour before moving on to the installation stage.

Installation of the Cummins QSB 4.5 Engine in the Dynapac CA2500D

After the overhaul and successful completion of the dynamometer test, the Cummins QSB 4.5 engine was prepared for reinstallation in the Dynapac CA2500D roller. Engine installation is just as important a stage of the entire process as the overhaul itself. A properly rebuilt engine must be correctly installed in the machine, and all connections must ensure tightness and proper cooperation with the remaining components.

During installation, the engine was positioned in the engine compartment using a crane provided by the customer. The power unit was positioned according to the location specified by the machine design and then secured. We checked the correct position of the mounts and the connection between the engine and the drive system components.

The next stage was connecting the lines and systems. Particular attention was paid to the cooling system because its proper operation is essential for maintaining the correct engine temperature during roller operation. The intake system components and air supply lines were also connected.

Replacement or proper preparation of the intake system lines is important not only to ensure correct airflow. All connections must be tight. A leak in the intake system can affect engine operation and its parameters. For this reason, after completing the connections, we check their condition and correct fastening.

Similar checks are carried out on the cooling system lines and other installations. Connections must be secured so that they do not become loose, damaged or displaced during machine operation. Proper routing of the lines in relation to moving and hot components is also important.

After the engine had been mechanically installed, the electrical system, fuel system and other components required for starting the unit were connected. Before start-up, we inspected the completed connections and prepared the machine for the initial tests. Appropriate filters are also replaced and the necessary procedures are performed to ensure proper engine start-up after the overhaul.

After starting the engine, we observed its operation while the machine was stationary. We checked the behaviour of the power unit, monitored for possible leaks and verified the correct operation of the systems working with the engine. Further tests were then carried out with the machine operator present.

Tests involving the operator are an important part of the final installation stage. The operator is familiar with the way the particular machine operates and can pay attention to the behaviour of the roller under conditions similar to normal operation. During the tests, engine operation over different working ranges and the unit's response to changes in load are checked.

After successful testing, a final inspection is performed. The connections, system tightness and general condition of the installation area are checked once again. After confirming correct engine operation and the absence of leaks, an installation report is prepared.

This approach to engine installation is intended not only to start the engine, but also to confirm proper cooperation between the power unit and the Dynapac CA2500D roller. This is particularly important for machines working intensively, where correct execution of all connections and checks affects subsequent operating reliability.

Engine Service After the Overhaul

Completion of the overhaul and installation of the Cummins QSB 4.5 engine does not mean the end of service support. After starting a rebuilt engine, it is important to carry out the first inspection after a specified period of operation. For engines overhauled by WIBAKO, we recommend carrying out the first inspection after 50 operating hours.

The 50-hour inspection is carried out by our mechanics. It is not limited to changing filters. During the service visit, the overall condition of the engine and its accessories is also checked after the initial operating period. Connections between the engine and other machine components are inspected, as well as the correct operation of the power unit.

The inspection after the first 50 operating hours can also identify possible leaks that may have appeared during normal machine operation. This is an important stage of post-overhaul service because connections and seals may be exposed to different conditions than during installation and the initial tests.

After the first inspection, subsequent inspections should be carried out every 250 operating hours, but not less frequently than once every 3 months. Regular service makes it possible to monitor the condition of the power unit and respond to potential irregularities at an early stage.

Cummins QSB 4.5 Engines in Construction and Road Machinery

Cummins QSB 4.5 engines are used in various off-highway machines where a durable and appropriately powerful power unit is required. In practice, engines from this family can be found in construction machinery, road machinery, agricultural equipment and other machines using diesel engines.

WIBAKO provides Cummins diesel engine service and repairs of power units used in construction machinery. When submitting a request for an engine overhaul, it is important to provide the exact engine model and machine details. This makes it easier to determine the appropriate diagnostic procedure and scope of work.

In the case of the Dynapac CA2500D roller, it is important to consider the operating characteristics of the machine. The engine does not operate only while the machine is travelling. The power unit works together with the entire machine system during soil compaction, which makes checking its behaviour under load particularly important after an overhaul.

Summary of the Cummins QSB 4.5 Engine Overhaul in the Dynapac CA2500D

The overhaul of the Cummins QSB 4.5 engine installed in the Dynapac CA2500D vibratory soil roller included the complete process from diagnostics in the machine, through removal, component inspection and rebuilding of the power unit, to dynamometer testing and reinstallation.

The starting point was a set of symptoms indicating wear of the crankshaft and connecting rod bearings. After removing the engine, we confirmed the need for a detailed inspection of the crankshaft and piston assembly. The crankshaft and connecting rods were checked along with the remaining engine components. The cylinder head and accessories were also inspected so that the prepared power unit could return to demanding operating conditions in the roller.

An important part of the entire process was the engine dynamometer test. The rebuilt Cummins QSB 4.5 was checked not only during start-up, but also under gradually increasing load. A minimum of 16 hours of operation at approximately 20-30% of nominal load, followed by further tests at higher loads, made it possible to assess the behaviour of the complete power unit before returning it to the machine.

After the tests were completed, the engine was reinstalled in the Dynapac CA2500D. During installation, particular attention was paid to the correct connection of the cooling, intake, fuel and electrical systems. Further operating tests were then performed with the machine operator present. Tightness and correct operation were checked before the installation process was completed.

WIBAKO also provides further service support for engines after overhaul. The first inspection after 50 operating hours makes it possible to check the condition of the engine and its accessories after the initial operating period. Subsequent inspections are carried out every 250 operating hours, but not less frequently than every 3 months.

If you need a Cummins engine overhaul, power unit diagnostics or construction machinery service, our mechanics can carry out engine removal and installation directly at the customer's site. After removal, the engine can be transported to our facility in Kojszówka, where we carry out detailed inspection, overhaul and engine dynamometer testing before reinstalling the unit.
