Hydraulic motor Linde HMV105-02 2342000058

The listed price applies when the old (used) product is returned.
Linde HMV105-02 hydraulic motor, 105 cm³, up to 500 bar, compact and efficient. Ideal for construction, agricultural, and industrial machinery.

  • Condition: new
  • SKU: 52061
Ocena 4,8

3 069.44 EURNet

- +

Product description

Linde Hydraulic Motor HMV105-02

Description

The Linde HMV105-02 hydraulic motor is a modern drive unit based on axial piston technology. Designed for use in hydrostatic drives in both open and closed circuits, it provides high efficiency, precise control, and long service life. With its compact design and modular construction, it can be easily integrated into various construction, agricultural, and industrial machines. It is characterized by high power density, low noise emissions, and the ability to operate in demanding environments.

Technical Data

  • Model: HMV105-02
  • Displacement: approx. 105 cm³/rev
  • Nominal operating pressure: up to 420 bar
  • Maximum pressure: up to 500 bar
  • Max. speed: approx. 2400 rpm
  • Torque: up to 700 Nm (depending on pressure)
  • Rotation: clockwise or counter-clockwise
  • Circuit type: open/closed
  • Operating temperature: -25°C to +90°C
  • Working fluid: hydraulic oils according to DIN 51524

Applications

The HMV series motors are widely used in travel drives, swing drives, and mechanisms requiring high power and precise control. They are applied in:
  • construction machinery (excavators, loaders, dumpers),
  • agricultural machinery,
  • industrial equipment,
  • drive systems of special vehicles.

Features

  • High energy efficiency and power density.
  • Compact design and modular regulator system.
  • Low noise emissions due to optimized design.
  • Long service life thanks to high-strength materials.
  • Precise control of flow and torque.
  • Suitable for heavy-duty applications.

Specification

Specification Value
name Hydraulic motor
mark Linde
type HMV105-02
part number 2342000058
condition new
displacement 105 cm³/rev
nominal pressure 420 bar
maximum pressure 500 bar
max. speed 2400 rpm
torque 700 Nm
operating temperature -25°C to +90°C

Reference numbers

List of reviews:

Patryk

2025-07-11

Zakup tego silnika to strzał w dziesiątkę. Szybka dostawa i świetna obsługa klienta. Jestem zadowolony z wyboru.
Mateusz

2025-05-05

Silnik działa bez zarzutu. Montaż był prosty, a wydajność znacznie poprawiła pracę maszyny. Polecam!
Henryk

2025-04-18

Bardzo dobra jakość produktu. Silnik hydrauliczny sprawdza się w trudnych warunkach. Zdecydowanie warto zainwestować.
Joshua

2025-04-02

The hydraulic motor exceeded my expectations. It was easy to install and has significantly improved the performance of my equipment. Highly recommend!
